11. Steering / Front Wheel / Front Fork
Place the front wheel between the front forks.
11-14
Align the groove on the speedometer gear
with the raised stopper on the left front fork.
Install the front wheel axle from the right fork.
Install the wheel axle nut and tighten it to the
specified torque value.
Torque value：6.0~8.0kgf-m
Assemble the speedometer cable to the
speedometer gear.
Stopper
Speedometer cable
Wheel axle nut
