Under the normal display status, press "SET" button 0.5 second, it can switch “VOLTAGE” display
mode or “CLOCK” display mode.
In time display mode, when the scooter is stationary , long press the "MODE" button more than 2
seconds, then it enter the time setting MODE, at this time press “MODE” button 1second, it can
switching over setting mode(Hour→minutes tens digit→minute single digits).
Short press "SET" button once, figure add 1.
In setting display mode, long press the "MODE" button for more than 2 seconds, it can leave the
setting mode.
Fault indicator light:
If there is something wrong with the ECU, the warning light will light all the time.
Engine oil change warning lamp:
It is used to indicate the oil exchange time, with lights, when the vehicle was driven about 1000
kilometers, indicator light will light up, warn the users to replace the oil.
After finish oil change, After the oil change, put the main switch in “ON”, short press "SET" button two
times in “OIL” mode, then the indicator light will go out.
ABS indicator light(ABS Model)(For:XH20W1-EGC,XH12WX-EU,XH20W1-DZC XH20W1-ZA):
Normally the ABS indicator light goes on when the ignition switch is turned on and goes off
shortly after the scooter starts moving.
The ABS (Anti-lock Brake System) indicator light goes on when the ignition switch is turned on and
goes off shortly after the scooter starts moving. If the ABS is normal, it stays off. If something is wrong
with the ABS, the indicator goes on and stays on. When the indicator light is on, the ABS does not
function but if the ABS fails, the conventional brake system will still work normally.
