Scanning 2 - 3
When the radio loses connection, the Bluetooth LED stops its slow, consistent blinking and the beeper emits a
short high low beep. The Bluetooth LED blinks at a faster rate for a period of time while the device attempts to
reestablish pairing with the host, and when it returns within range the device repairs. If repairing is
unsuccessful the Bluetooth LED stops blinking.
To manually reestablish paring when the device returns to range, press the Bluetooth LED button. Upon
Bluetooth pairing, the beeper emits a short low high beep and the Bluetooth LED starts its slow, consistent
blinking again.
User Interface Definitions
The scanner uses beeper and LED sequences to indicate various system events. Table 2-1 and Table 2-2
define these sequences and events.
LED Indications
Table 2-1
LED Indications
Function Performed User Action LED Feedback Other
Scan attempt Press scan (+)
button
Flashing green Imager on
Successful bar code scan Solid green Imager off
Battery charge status Press battery
charge button
4 green Full charge (12 hours in a
busy environment)
3 green Approximately 3/4 charge
2 green Approximately 1/2 charge
1 green Approximately 1/4 charge
Delete bar code
(when in batch mode)
Press & hold
delete (-) button
Flashing amber Imager on
Successful bar code deletion Solid amber Imager off
Unsuccessful deletion - item
doesn't exist (when in batch
mode)
Solid red Imager off
Clear all bar code data
(when delete (-) button enabled)
Hold delete (-)
button 3 seconds
past scan time
Flashing amber Imager on
Successful clear all Solid amber Imager off
Charge scanner Connect scanner
to a host PC USB
port
Flashing amber Scanner connects in mass
storage mode, auto-run
application on PC launches
Charge complete Solid green
