Chapter 1 Getting Started
Preparing the GPS Receiver for Use
1-10 Getting Started Guide
3 Slide the cable sleeve (6) over the cable (7).
4 Loosen the screw of 5 (L) terminal, and connect the positive (high)
voltage wire to the terminal.
The “L” terminal marking is inscribed inside the bottom cover (9).
5 Tighten screw. Soldering is not necessary.
6 Loosen the screw of 3 (N) terminal, and connect the negative (low)
voltage wire to the terminal.
The “N” terminal marking is inscribed inside the bottom cover (9).
7 Tighten screw. Soldering is not necessary.
8 Loosen the screw of 4 ( ) terminal, and connect the ground (chassis)
wire to the terminal.
The “ ” terminal marking is inscribed inside the bottom cover (9).
9 Tighten screw. Soldering is not necessary.
10 With the wires connected to the terminals (3, 4, and 5), re-insert the
terminal in their proper positions in the bottom cover (9).
11 Make sure that the cable sleeve’s (6) brim is placed in the groove or slot
in the bottom cover (9).
12 Clamp the wires down using the wire clamp (8). Position the clamp and
over the wires and attach and secure it to bottom cover (9) by
tightening the two screws (10).
At this point, your connector plug and cable assembly should look
similar to Figure 1-2B.
