Chapter 1 Getting Started
Preparing the GPS Receiver for Use
Getting Started Guide 1-11
Figure 1-2B. 129 Vdc DC Power Cable Assembly
13 As shown in Figure 1-2B, join the two covers (2, 6) by properly
positioning them together and tightening the wire clamp screws (4).
14 Finally, secure the two covers by tigthening the cover screw (1).
15 Observing the correct polarity, attach the other ends of the wires to a
proper dc power source to operate the Module.
1 Cover screw 4 Wire clamp screws
2 Top cover 5
Wire clamp
3 Cable sleeve 6 Bottom cover
1
2
6
5
4
3
4
