20
Rev. 12GB0712
SYSTEMA S.p.A.
AIRTIGHT GAS CONVECTORS
Draw 15
3 INSTRUCTIONS FOR INSTALLERS
3.1 Places of installation and
safety distances
We recommend observing the following rules in order to
obtain the maximum convector output efficiency:
- Position the device while bearing in mind the priority
areas to be heated, the absorption walls (windows,
doors, French windows etc.), and the existence of
shelves and other obstacles that might compromise
the circulation of the hot air released by the radiator
above and the effect of the heat radiated from the
front panel.
- If more than one device must be installed in the
same room, we recommend staggered and oppo-
sing positioning in order to provide the entire area
with uniform coverage.
- The devices must never be installed in recessed
niches or positions that do not ensure sufficient
aeration for good operation.
- Install the devices along perimetral walls whenever
possible.
- Observe the following rules to simplify interven-
tions on the radiator or the removal of the shell:
a) the distance of the device from the floor must
never be less than 10 cm.;
b) any shelves installed above the radiator must be
positioned at least 10 cm higher;
c) a minimum distance of 10 cm from the wall must
be respected whenever devices are installed in
recessed niches;
- avoid positioning furnishings above the shell.
Installation must be performed only by qualified profes-
sionals in complete respect of the safety regulations in
force. The Manufacturer declines all liability for erro-
neous installation or the inappropriate or incorrect use of
the device.
