15



d.1.6Pictogramsforallavailablefunctionsintheunits

Id Description Symbol

DVA Damper

DVB Damper

DVM Damperformixing

DVP Damperformixing

DVG Panelfilter

DVF Bagfilter

DVC Rotaryheatexchanger

DVQ Plateheatexchanger(crossflowandcounterflow) 

DVR Runaroundheatexchanger 

DVH Heatingbattery 

DVK Coolingbattery

DVU Integratedcoolingwithcompressorunit 
