Thereare4differentmanualsandeachofthemillustratestheassemblyofthe4differenttypesofbase
frames:
1. Manualaboutthe150mmhighbaseframesforAHUsinthesizesfromDV10toDV40.The
nameofthismanualis–Baseframe150DVZ
10‐40
2. Manualaboutthe150mmhighbaseframesforAHUsinthesizesfromDV50toDV150.The
nameofthemanualis–Baseframe150DVZ50‐150
3. Manualaboutthe250mmhighbaseframesforAHUsinthesizesfrom
DV10toDV40.The
nameofthemanualis–Baseframe250DVZ10‐40
4. Manualaboutthe250mmhighbaseframesforAHUsinthesizesfromDV50toDV150.The
nameofthemanualis–Baseframe250DVZ50‐150


Exampleof150mmhighbaseframeforAHUsinthesizefromDV50toDV150


Mountadjustablefeetwithadistanceofmaximum1500mmbetweeneachfootunderthebaseframe.The
baseframecannowbelevelledbytheadjustablefeet.Thenextstep
istoplaceandassembleAHUsections
onthebaseframe.
i.2.5Baseframesforoutdoorunits
Outdoorunitsmustbeinstalledon250mmhighbas eframesandarealwaysfittedtotheAHUsections.
Hot‐dipgalvanizedbaseframesarerecommendedforoutdoorunits.Systemairdeliversthesebaseframes
withouttheabovementionedadjustablefeet.
i.2.6Installationonthesiteofunitsectionsatthebaseframewhensectionsare
deliveredonpallets.
Liftupthesectionbyhandmanualforkliftstothelevelwheretheundersideofthesectionisevenwiththe
oversideofthebaseframe.
1. Pullthesectiontothecorrectpositiononthebaseframebyliftingstraps–itismaybenecessaryto
supportthesectionby
heavydutyfurnituretrolleys(seethephotosbelow)

Exampleofheavydutyfurniture
trolleyturnedwiththewheels
upwards.Placedinthiswayon
theforksofthehandmanual
forkliftstheheavydutyfurniture
trolleysaresuitableforsafeand
carefulrollingoftheunit
sectionsovertothebaseframes.
