28



2. Pullsectionstogetherwithliftingstraps.Werecommendthebelowshowntypeofbrackets

becausethistypeisnotdamagingtheframeprofilesoftheunits.Anexampleofliftingstrapsis

shownbelow.



Exampleofveryheavyduty

furnituretrolleys.Turned

withthewheelsupwardsand

placedontheforksofhand

manualforkliftstheseheavy

dutyfurnituretrolleysare

verysuitableforsafeand

carefulrollingoftheunit

sectionsovertothebase

frames.
