Portbase User Guide
PortView IP Address (Default: 0.0.0.0 / 4000)
When Portbase management software Portview is used,
Set IP address and the socket number of the server PC on which Portview is installed.
(Refer to
Chapter 5. Management with Portview for further information.)
SNMP (Default : Disable)
When standard SNMP server manages Portbase,
determine if SNMP Agent service will be used or not.
MIB-II (RFC 1213): System, Interface, IP, ICMP, TCP, UDP
MIB-I (RFC 1317): Serial Interface
Time Server (Default: 0.0.0.0)
Set the Time Server to provide correct time in the region and the country in which Portbase is
located. Portbase has a default Time Server registered. Other Time Servers can be registered if
needed.
Time Zone (Default: Seoul)
When the default Time Server registered in Portbase is activated, select the region and the
country in which Portbase is located.
31
