T-solution SV-iG5 User Manual

99
CHAPTER 7 - OPTIONS
7.1 Braking Resistor
Braking resistor is optional.
7.1.1 Lower Braking Magnitude
Model Number
SvxxxiG5-x
004-1/2 008-1/2 015-1/2 022-2
037-2
040-2
004-4 008-4 015-4 022-4
037-4
040-4
Enable Duty [%] 5 5 3 2 2 5 5 3 2 2
Duty
Continuous Braking
Time [Sec]
5 5 5 5 5 5 5 5 5 5
Resistor Value [Ω]
400 200 100 60 40 1800
900 450 300 200
Resistor
Resistor Capacity [W] 100 100 100 100 100 100 100 100 100 100
7.1.2 Higher Braking Magnitude
[200V Class]
Model Number
SvxxxiG5-x
004-1/2 008-1/2 015-2/1 022-2
037-2
040-2
Average Braking Torque [%] 100 150 100 150 100 150 100 150 100 150
Enable Duty [%] 5 5 5 5 5 5 5 5 5 5
Duty
Continuous Braking
Time [Sec]
5 5 5 5 5 5 5 5 5 5
Resistor Value [Ω]
400 300 200 150 100 60 60 50 40 33
Resistor
Resistor Capacity [W] 100 150 100 150 200 300 300 400 600 600
[400V Class]
Model Number
SvxxxiG5-x
004-4 008-4 015-4 022-4
037-4
040-4
Average Braking Torque [%] 100 150 100 150 100 150 100 150 100 150
Enable Duty [%] 5 5 5 5 5 5 5 5 5 5
Duty
Continuous Braking
Time [Sec]
5 5 5 5 5 5 5 5 5 5
Resistor Value [Ω]
1700 1200
900 600 450 300 300 200 200 130
Resistor
Resistor Capacity [W] 60 80 100 150 200 300 300 400 500 600
