T-solution SV-iG5 User Manual

104
APPENDIX B- PERIPHERAL DEVICES
Wire, mm
2
(AWG) Inverter
Models
Motor
[HP]
MCCB, ELB
Magnetic
Contactor
R,S,T U,V,W Ground
AC Input
Fuse
AC Reactor
SV004iG5-1 0.5 ABS33a, EBS33 GMC-9P 2 (14) 2 (14) 3.5 (12) 10 A 2.13 mH, 5.7 A
SV008iG5-1 1 ABS33a, EBS33 GMC-9P 2 (14) 2 (14) 3.5 (12) 10 A 2.13 mH, 5.7 A
SV015iG5-1 2 ABS33a, EBS33 GMC-9P 2 (14) 2 (14) 3.5 (12) 15 A 1.20 mH, 10 A
SV004iG5-2 0.5 ABS33a, EBS33 GMC-9P 2 (14) 2 (14) 3.5 (12) 10 A 2.13 mH, 5.7 A
SV008iG5-2 1 ABS33a, EBS33 GMC-9P 2 (14) 2 (14) 3.5 (12) 10 A 2.13 mH, 5.7 A
SV015iG5-2 2 ABS33a, EBS33 GMC-9P 2 (14) 2 (14) 3.5 (12) 15 A 1.20 mH, 10 A
SV022iG5-2 3 ABS33a, EBS33 GMC-9P 2 (14) 2 (14) 3.5 (12) 25 A 0.88 mH, 14 A
SV037iG5-2 5 ABS33a, EBS33 GMC-18P 3.5 (12) 3.5 (12) 3.5 (12) 40 A 0.56 mH, 20 A
SV040iG5-2 5.4 ABS33a, EBS33 GMC-18P 3.5 (12) 3.5 (12) 3.5 (12) 40 A 0.56 mH, 20 A
SV004iG5-4 0.5 ABS33a, EBS33 GMC-9P 2 (14) 2 (14) 2 (14) 6 A 8.63 mH, 2.8 A
SV008iG5-4 1 ABS33a, EBS33 GMC-9P 2 (14) 2 (14) 2 (14) 6 A 8.63 mH, 2.8 A
SV015iG5-4 2 ABS33a, EBS33 GMC-9P 2 (14) 2 (14) 2 (14) 10 A 4.81 mH, 4.8 A
SV022iG5-4 3 ABS33a, EBS33 GMC-9P 2 (14) 2 (14) 2 (14) 15 A 3.23 mH, 7.5 A
SV037iG5-4 5 ABS33a, EBS33 GMC-12P 2 (14) 2 (14) 2 (14) 20 A 2.34 mH, 10 A
SV040iG5-4 5.5 ABS33a, EBS33 GMC-12P 2 (14) 2 (14) 2 (14) 20 A 2.34 mH, 10 A
