T-solution SV-iG5 User Manual

Chapter 3 - Parameter List
26
3.3 Function Group 2 [FU2]
Code Description
Keypad
Display
Setting Range Units
Factory
Default
Adj.
During
Run
Page
FU2-00 Jump to Desired Code # H 0 1 to 99 1 30 Yes 49
FU2-01 Previous Fault History 1 H 1
FU2-02 Previous Fault History 2 H 2
FU2-03 Previous Fault History 3 H 3
FU2-04 Previous Fault History 4 H 4
FU2-05 Previous Fault History 5 H 5
-
None
n0n
-
0 (No)
FU2-06 Erase Fault History H 6
1 (Yes)
- 0 (No) Yes
49
FU2-07 Dwell Frequency H 7 0 to FU1-20 0.01 5.00 [Hz] No
FU2-08 Dwell Time H 8 0 to 10 [sec] 0.1 0.0 [sec] No
49
0 (No)
FU2-10 Frequency Jump Selection H 10
1 (Yes)
- 0 (No) No
FU2-11
12
Jump Frequency 1 Low H 11 0.00 to (FU2-12) 0.01 0.00 [Hz] No
FU2-12 Jump Frequency 1 High H 12 (FU2-11) to (FU1-20) 0.01 0.00 [Hz] No
FU2-13 Jump Frequency 2 Low H 13 0.00 to (FU2-14) 0.01 0.00 [Hz] No
FU2-14 Jump Frequency 2 High H 14 (FU2-13) to (FU1-20) 0.01 0.00 [Hz] No
FU2-15 Jump Frequency 3 Low H 15 0.00 to (FU2-16) 0.01 0.00 [Hz] No
FU2-16 Jump Frequency 3 High H 16 (FU2-15) to (FU1-20) 0.01 0.00 [Hz] No
50
FU2-19 Input/Output Phase Loss Protection H 19
00 – 11 (bit set)
Bit 0: Output Phase
Loss Protection
Bit 1: Input Phase
Loss Protection
- 00 Yes 50
0 (No)
FU2-20 Power ON Start Selection H 20
1 (Yes)
- 0 (No) Yes 51
0 (No)
FU2-21 Restart after Fault Reset H 21
1 (Yes)
- 0 (No) Yes 51
FU2-22 Speed Search Selection H 22
0000 – 1111 (bit set)
Bit 0: During Accel.
Bit 1: After Fault reset
Bit 2: After Instant
Power Failure restart
Bit 3: When FU2-20 is
set to 1 (Yes).
- 0000 No 52
FU2-23
Current Limit Level During Speed
Search
H 23 80 to 250 [%] 1 180 [%] Yes 52
12
Code FU2-11 through FU2-16 appears only when FU2-10 is set to ‘Yes’.
