CHAPTER 3 - PARAMETER LIST
3.1 Drive Group [DRV]
Code Description
Keypad
Display
Setting Range Units
Factory
Default
Adj.
During
Run
Page
DRV-00
Output Frequency during running,
Reference Frequency during stop
0.00 0.00 to (FU1-20) 0.01 00.00 [Hz] Yes 33
DRV-01 Acceleration Time ACC 0.0 to 999.9 [sec] 0.1 10.0 [sec] Yes 33
DRV-02 Deceleration Time DEC 0.0 to 999.9 [sec] 0.1 20.0 [sec] Yes 33
0 (keypad)
1 (Fx/Rx-1)
2 (Fx/Rx-2)
DRV-03
Drive Mode
(Run/Stop Method)
Drv
3 (RS485)
- 1 (Fx/Rx-1) No 34
0 [Keypad-1]
1 (Keypad-2)
2 (V1)
3 (I)
4 (V1+I)
DRV-04
Frequency Mode
(Freq. Setting Method)
Frq
5 (RS485)
- 0 [Keypad-1] No 34
DRV-05 Step Frequency 1 St1 10.00 [Hz]
DRV-06 Step Frequency 2 St2 20.00 [Hz]
DRV-07 Step Frequency 3 St3
0.00 to (FU1-20) 0.01
30.00 [Hz]
Yes 35
DRV-08 Output Current Cur * [A] - - [A] - 35
DRV-09 Motor Speed RPM * [rpm] - - [rpm] - 35
DRV-10 DC link Voltage DCL * [V] - - [V] - 36
DRV-11 User Display Selection
vOL,
Por,
tOr
Selected in FU2-73
(User disp)
- - - 36
DRV-12 Fault Display nOn - -
None
nOn
- 36
F (Forward)
DRV-13 Motor Direction Set drc
r (Reverse)
- F (Forward) Yes 36
DRV-20 FU1 Group Selection FU1 37
DRV-21 FU2 Group Selection FU2 37
DRV-22 I/O Group Selection I O 37
