T-solution SV-iG5 - Parameter Code List

Chapter 5 - MODBUS-RTU Communication
80
5.7 Parameter Code List
< Common >
Parameter
address
Description Unit Read/Write Data value (HEX) Note
0000 Inverter model - R 7: SV-iG5
0001 Inverter capacity - R
0: 0.5Hp, 1: 1Hp, 2: 2Hp
3: 3Hp, 4:5Hp, 5: 5.4Hp
0002 Inverter input voltage - R 0: 220V class, 1:440V class
0003 Version - R
313043: Version 1.0C
353043: Version 5.0C
0004 Parameter write enable - R/W
0: Write disable (default)
1: Write enable
0005 Reference frequency 0.01 Hz R/W
0006 Operation reference - R/W
Bit 0: Stop (R/W)
Bit 1: Forward (R/W)
Bit 2: Reverse (R/W)
Bit 3: Fault reset (W)
Bit 4: Emergency stop (W)
0007 Accel time 0.1 sec R/W
0008 Decel time 0.1 sec R/W
0009 Output current 0.1 A R
000A Output frequency 0.01 Hz R
000B Output voltage 1 V R
000C DC Link voltage
0.1 V R
000D Output power Not used
000E Operating status - R
Bit 0: Stop
Bit 1: Forward
Bit 2: Reverse
Bit 3: Fault (Trip)
Bit 4: Accelerating
Bit 5: Decelerating
Bit 6: Speed reached
Bit 7: DC Braking
000F Trip info - R
Bit 0: OC
Bit 1: OV
Bit 2: EXT
Bit 3: BX
Bit 4: LV
Bit 5: Fuse Open
Bit 6: GF
Bit 7: OH
0010 Input terminal info - R
Bit 0: FX
Bit 1: RX
