Chapter 5 - MODBUS-RTU Communication
81
Parameter
address
Description Unit Read/Write Data value (HEX) Note
Bit 2: BX
Bit 3: RST-
Bit 8: P1
Bit 9: P2
Bit 10: P3
0011 Output terminal info - R Bit 0: Q1 (OC)
0012 V1 - R 0 – FFFF
0013 V2 - - Not used
0014 I - R 0 – FFFF
0015 RPM - R
< DRV Group >
Parameter
address(*3)
Parameter
Code
Description
Default
value
Max. value Min. value Unit Note
6100 DRV #00 Cmd. Freq. 5000 FU1-20 (*1) FU1-22 (*2) 0.01Hz
6101 DRV #01 Acc. Time 100 9999 0 0.1 sec
6102 DRV #02 Dec. Time 200 9999 0 0.1 sec
6103 DRV #03 Drive mode 1 2 0
6104 DRV #04 Freq. mode 2 4 0
6105 DRV #05 Speed - 1 1000 FU1-20 0 0.01Hz
6106 DRV #06 Speed - 2 2000 FU1-20 0 0.01Hz
6107 DRV #07 Speed - 3 3000 FU1-20 0 0.01Hz
6108 DRV #08 Output Current 0 - - 0.1A Read Only
6109 DRV #09 Output speed 0 - - RPM Read Only
610A DRV #10 DC Link Voltage
0 - - 0.1V Read Only
(*1) Refer to FU1 #20 for Max Freq.
(*2) Refer to FU1 #22 for Start Freq.
(*3) Parameter address is HEX data
< FU1 Group >
Parameter
address
Parameter
Code
Description
Default
value
Max. value Min. value Unit Note
6203 FU1 #03 Run prohibit 0 2 0
6205 FU1 #05 Acc. pattern 0 4 0
6206 FU1 #06 Dec. pattern 0 4 0
6207 FU1 #07 Stop mode 0 2 0
6208 FU1 #08 DcBr freq. 500 5000 FU1-22 0.01 Hz
6209 FU1 #09 DcBlk time 10 6000 0 0.01 sec
620A FU1 #10 DcBr value 50 200 0 1%
620B FU1 #11 DcBr time 10 600 0 0.1sec
