T-solution SV-iG5 - Page 33

Chapter 3 - Parameter List
28
Code Description
Keypad
Display
Setting Range Units
Factory
Default
Adj.
During
Run
Page
3 (Drv Mode)
4 (Freq Mode)
5 (Step Freq 1)
6 (Step Freq 2)
7 (Step Freq 3)
8 (Current)
9 (Speed)
10(DC Link Vtg)
11 (User Display)
12 (Fault Display)
13 (Motor Direction)
0 (Voltage)
1 (Watt)
FU2-73 User Display Selection H 73
2 (Torque)
- 0 (Voltage) Yes 57
FU2-74 Gain for Motor Speed Display H 74 1 to 1000 [%] 1 100 [%] Yes 57
0 (None)
1 (None)
FU2-75
DB (Dynamic Braking) Resistor Mode
Selection
H 75
2 (Ext. DB-R)
- 2 (Ext. DB-R)
Yes 58
FU2-76 Duty of Dynamic Braking Resistor H 76 0 to 30 [%] 1 10 [%] Yes 58
FU2-79 Software Version H 79
.
-
.
- 58
FU2-81
17
2
nd
Acceleration Time H 81 0.0 to 999.9 [sec] 0.1 5.0 [sec] Yes
FU2-82 2
nd
Deceleration Time H 82 0.0 to 999.9 [sec] 0.1 10.0 [sec] Yes
FU2-83 2
nd
Base Frequency H 83 30 to FU1-20 0.01 50 / 60 [Hz] No
0 (Linear)
1 (Square)
FU2-84 2
nd
V/F Pattern H 84
2 (User V/F)
- 0 (Linear) No
FU2-85 2
nd
Forward Torque Boost H 85 0 to 15 [%] 0.1 2.0 [%] No
FU2-86 2
nd
Reverse Torque Boost H 86 0 to 15 [%] 0.1 2.0 [%] No
FU2-87 2
nd
Stall Prevention Level H 87 30 to 250 [%] 1 200[%] No
FU2-88
2
nd
Electronic Thermal Level for 1
Minute
H 88 FU2-89 to 250 [%] 1 180 [%] Yes
FU2-89
2
nd
Electronic Thermal Level for
Continuous
H 89 50 to (FU2-88) 1 120 [%] Yes
FU2-90 2
nd
Rated Motor Current H 90 0.1 to 99.9 [A] 0.1 - [A] No
58
0 (No)
FU2-91
Read Parameters into Keypad from
Inverter
H 91
1 (Yes)
- 0 (No) No
0 (No)
FU2-92
Write Parameters to Inverter from
Keypad
H 92
1 (Yes)
- 0 (No) No
59
17
Code FU2-81 through FU2-90 appears only when one of I/O-12 ~ I/O-14 is set to ‘2nd function’.
