T-solution SV-iG5 - Page 89

Chapter 5 - MODBUS-RTU Communication
84
Parameter
address
Parameter
Code
Description
Default
value
Max. value Min value Unit Note
6354 FU2 #84 2nd V/F 0 2 0
6355 FU2 #85 2nd F-boost 20 150 0 0.1%
6356 FU2 #86 2nd R-boost 20 150 0 0.1%
6357 FU2 #87 2nd Stall 200 250 30 %
6358 FU2 #88 2nd ETH 180 250 FU2-89 %
6359 FU2 #89 2nd ETH 120 FU2-88 50 %
635A FU2 #90 2nd R-Curr 18 999 1 0.1A
(*1), (*2), (*3) values vary according to the capacity.
< I/O Group>
Parameter
address
Parameter
Code
Description
Default
value
Max. value Min value Unit Note
6401 I/O #01 V1 filter 100 9999 0 ms
6402 I/O #02 V1 volt x1 0 IO-04 0 0.01V
6403 I/O #03 V1 freq y1 0 FU1-20 0 0.01Hz
6404 I/O #04 V1 volt x2 1000 1200 IO-02 0.01V
6405 I/O #05 V1 freq y2 5000 FU1-20 0 0.01Hz
6406 I/O #06 I filter 100 9999 0 ms
6407 I/O #07 I curr x1 400 IO-09 0 0.01 mA
6408 I/O #08 I freq y1 0 FU1-20 0 0.01 Hz
6409 I/O #09 I curr x2 2000 2400 IO-07 0.01 mA
640A I/O #10 I freq y2 5000 FU1-20 0 0.01 Hz
640B I/O #11 Wire broken 0 2 0
640C I/O #12 P1 define 0 26 0
640D I/O #13 P2 define 1 26 0
640E I/O #14 P3 define 2 26 0
640F I/O #15 In Status
6410 I/O #16 Out Status
6411 I/O #17 TI Filt Num 2 20 2
6414 I/O #20 Jog freq 1000 FU1-20 0 0.01 Hz
6415 I/O #21 Speed - 4 4000 FU1-20 0 0.01 Hz
6416 I/O #22 Speed - 5 5000 FU1-20 0 0.01 Hz
6417 I/O #23 Speed - 6 4000 FU1-20 0 0.01 Hz
6418 I/O #24 Speed - 7 3000 FU1-20 0 0.01 Hz
6419 I/O #25 Acc - 1 200 9999 0 0.1 sec
641A I/O #26 Dec - 1 200 9999 0 0.1 sec
641B I/O #27 Acc - 2 300 9999 0 0.1 sec
641C I/O #28 Dec - 2 300 9999 0 0.1 sec
641D I/O #29 Acc - 3 400 9999 0 0.1 sec
641E I/O #30 Dec - 3 400 9999 0 0.1 sec
641F I/O #31 Acc – 4 500 9999 0 0.1 sec
