tae TA-U65 User Manual

Appendix 1 list of Parameters State 16.11.15
Misprints and technical changes reserved Page 28
18: Positioning
ID
Name
Value-Range
Default-Value
Unit
Access
847
Reference position
0 ... 2147483647
0
Imp
RW
848
Adjust brake curve time
0,0 ... 600,0
0,2
s
RW
849
Actual reference position
-2147483647 ... 2147483647
---
Imp
R
850
Actual position
-2147483647 ... 2147483647
---
Imp
R
851
Actual position difference
-2147483647 ... 2147483647
---
Imp
R
852
P-amplification near pos. window
0 ... 100
0
RW
853
Zero reference position
-2147483647 ... 2147483647
0
Imp
RW
20: Brake Systems
ID
Name
Value-Range
Default-Value
Unit
Access
860
Brake System Control
0000h ... 0003h
0000h
RW
Bit
Name
Note
0
Enable Brake System
Activated control of brake by drive.
Caution! Digital output Terminal 13 is reserved for addressing the brake.
Other interlinks to Terminal 13 (Par.210 Bit 9) have no function.
1
Brake System with
Feedback
Acknowledge contact integrated in controls
20: Brake Systems
ID
Name
Value-Range
Default-Value
Unit
Access
861
Brake System Status
0000h ... 001Fh
---
R
Bit
Name
Note
0
Brake System Enabled
Braking system is active
1
Brake System with
Feedback
Brake equipped with Feedback contact
2
Brake Feedback Signal
Pending (Brake bled). Feedback must be linked with this Bit via the digital
input and SPC function.
3
Brake loosened
Brake is basically addressed with this Bit via relay output terminal 13. Other
interlinks to Terminal 13 (Par.210 Bit 9) have no function.
4
Brake Feedback Signal Error
Addressing of brake and feedback do not match!
Drive is set to Holding function until regulator is blocked and Reset has
been performed!
5
Brake leaded Decleration
Controlled run-down is activated automatically
20: Brake Systems
ID
Name
Value-Range
Default-Value
Unit
Access
862
Brake Delay start time
0 ... 60000
0
ms
RW
863
Brake Delay stop time
0 ... 60000
0
ms
RW
21: Keypad PG4000
ID
Name
Value-Range
Default-Value
Unit
Access
700
menu_control
0000h ... 0011h
0000h
RW
Bit
Name
Function
0
Inhibit Err-/Warn Messages
Disable error and warning messages on the Keypad
1…3
4
Reset GetText
Reset text buffer
21: Keypad PG4000
ID
Name
Value-Range
Default-Value
Unit
Access
701
pg4000_timeout
1 ... 5000
100
ms
RW
702
keypad_delay_init
1 ... 1000
10
RW
703
keypad_delay_repeat
1 ... 1000
2
RW
