tae TA-U65 User Manual

Appendix 1 list of Parameters State 16.11.15
Misprints and technical changes reserved Page 29
21: Keypad PG4000
ID
Name
Value-Range
Default-Value
Unit
Access
704
sercom_protocol
0 ... 2
0
RW
705
Menu.refresh_cycle_time
0 ... 2000
200
ms
RW
706
Menu-Language
[00] English ... [01] Deutsch
[00] english
RW
720
KEYS_Bitmap
0000h ... 003Fh
0000h
[bits]
R
721
keypad_run
0000h ... 003Fh
0000h
[bits]
R
722
KEYS_Counter[0]
0 ... 256
0
R
723
KEYS_Counter[1]
0 ... 256
0
R
724
KEYS_Counter[2]
0 ... 256
0
R
725
KEYS_Counter[3]
0 ... 256
0
R
726
KEYS_Counter[4]
0 ... 256
0
R
727
KEYS_Counter[5]
0 ... 256
0
R
22: Error Log
ID
Name
Value-Range
Default-Value
Unit
Access
800
errlog_ctrl
0000h ... F331h
0000h
RW
Bit
Name
Function
0
Suspend Log
Stop recording
1
-
2
-
3
-
4
No WrapAround
Disable ring buffer (no overwriting of old entries)
5
Reverse Order
Reverse order sequence of Entry Selector
6
-
7
-
8
Clear History
Delete Logbook
9
Reset History
Reset Logbook
10…15
-
22: Error Log
ID
Name
Value-Range
Default-Value
Unit
Access
801
errlog_status
0000h ... 0011h
---h
R
Bit
Name
Function
0
Error active
Error status is active
1…3
4
Hist_limit_reached
Error Logbook is full
22: Error Log
ID
Name
Value-Range
Default-Value
Unit
Access
802
errlog_eep_config.n_errors
0 ... 100
---
R
803
errlog_selector_idx
0 ... 99
---
R
804
errlog_selector
-100 ... 100
0
RW
805
errlog_selector_accepted
-100 ... 100
---
R
806
errlog_selected_logitem.time
2000-00-00T00:00:00 ... 2063-15-31T31:63:63
---
R
807
errlog_selected_logitem.error
0000h ... FFFFh
---h
[bits]
R
808
errlog_selected_logitem.xerror
0000h ... FFFFh
---h
[bits]
R
813
errlog_eep_config.last_idx
-1 ... 100
---
R
814
errlog_act_errors
0000h ... FFFFh
---h
[bits]
R
815
errlog_act_errors_mask
0000h ... FFFFh
FFFFh
[bits]
RW
816
errlog_act_errors_DBG
0000h ... FFFFh
0000h
[bits]
R
817
errlog_eep_errors_read
0 ... 100
---
R
818
errlog_eep_errors_write
0 ... 100
---
R
