tae TA-U65 User Manual

Appendix 1 list of Parameters State 16.11.15
Misprints and technical changes reserved Page 30
22: Error Log
ID
Name
Value-Range
Default-Value
Unit
Access
819
errlog_time_now
2000-00-00T00:00:00 ... 2063-15-31T31:63:63
---
R
Current system time of regulator in T32 format
T32 Time Format
Timestamps are saved in the Error Logbook in a compact double word format. The structure of the bit field is as
follows:
T32 Time Format – Bit Field Description
Offset
N Bits
Name
Value Range
0
6
Seconds
(0 … 59)
6
6
Minutes
(0 … 59)
12
4
Month
(0 … 11)
16
5
Hour
(0 … 23)
21
5
Day
(1 … 31)
27
6
Years since 2000
(0 … 63)
A time range from 2000-00-00T00:00:00 yo 2063-15-31T23:59:59 can therefore be displayed with this.
23: Trace
ID
Name
Value-Range
Default-Value
Unit
Access
1000
trace command
0000h ... 0037h
0000h
[bits]
RW
Bit
Name
Function
0
Start Now
Start Trace
1
Start On Trigger
Start Trace including Trigger condition
2
Run Idle
Activate Non-Real-time Trace
3
–
–
4
Cancel
Cancel current Trace
5
Reset
Cancel current Trace and reset error/status flags
6…15
23: Trace
ID
Name
Value-Range
Default-Value
Unit
Access
1001
trace status
0000h ... F133h
---h
[bits]
R
Bit
Name
Function
0
Trace Running
Trace is currently active
1
Idle Running
Idle-Trace (Polling Mode) is active
2
3
4
Trace done
Trace is completed
5
Trigger active
Trigger condition is currently fulfilled
6
7
8
Trace N/A
Trace function is not available
9
10
11
12
Err#TrigParam
Error: Invalid Trigger Parameter [1011]
13
Err#BufferOvrun
Error: Trace buffer overflow
14
Err#BankSel
Error: Invalid Trace Bank Selector [1040]
15
Err#ChSize
Error: Maximum size of all Trace channels exceeded
