7. Installation

7.1 FY400 Dimensions

(Unit: mm)

Dimensions

Individual mounting

7.2 FY600 Dimensions

(Unit: mm)

Dimensions

Individual mounting

t (panel thickness) 1~t~6

Mounting fixture

7.3 FY700 Dimensions

(Unit: mm)

Dimensions

Individual mounting
