Taie FY700 - FA Series Specifications

7 FY operation manual
3.2 FA Specifications
Model
FA231
FA230
Terminal
Fixed
Pluggable
Supply Voltage
AC 85 ~ 265V, DC 24V (Optional Functions)
Power Frequency
50/60 Hz
Power Consumption
Approximately 6VA
Memory
Non-Volatile Memory EEPROM
Sensor Input
※
Please refer to Input
Range Table
Accuracy : 0.2%
Sample time : 50ms
Thermocouple : (K, J, R, S, B, E, N, T, W, PL
Ⅱ
, L)
RTD : PT100
DC Linear Analog Input : 0~20mA, 4~20Ma
0~1V, 0~5V, 0~10V, 0~2V, 1~5V, 2~10V
0~25mV, 0~50mV, 0~70mV
Output
OUT1 Relay
1a
1c
1a SPST-NO, 250 VAC, 5A (resistive load), electrical life: 100,000 operations
1c SPDT-NO, 250 VAC, 5A (resistive load), electrical life: 50,000 operations
SPDT-NC, 250 VAC, 2A (resistive load), electrical life: 20,000 operations
OUT2 Relay
SPST-NO, 250 VAC, 5A (resistive load), electrical life: 100,000 operations
SSR Driver
ON: 24 V OFF: 0V max. load current: 20mA, with short circuit protection circuit
linear
4~20mA,0~20mA, 0~5V,0~10V, 1~5V,2~10V
Control Method
ON-OFF or P, PI, PID control
Alarm
Alarm 1
1a
1c
1a SPST-NO, 250 VAC, 5A (resistive load), electrical life: 100,000 operations
1c SPDT-NO, 250 VAC, 5A (resistive load), electrical life: 50,000 operations
SPDT-NC, 250 VAC, 2A (resistive load), electrical life: 20,000 operations
Alarm 2
SPST-NO, 250 VAC, 5A (resistive load), electrical life: 100,000 operations
TRS
Re-transmitted
Signal
4~20mA, 0~20mA, 0~5V, 0~10V, 1~5V, 2~10V
Source of Re-
transmission
SV, PV
Accuracy
0.1%
Resolution
14 bit
Remote
SV
Signal
4~20mA, 0~20mA, 0~5V, 0~10V, 1~5V, 2~10V
Resolution
18 bit
controlled by
SV
Commun
ication
Interface
RS-485 Half duplex Communication MAX. 31 units, MAX. distance 1200 meters
Protocol
Modbus RTU , TAIE
Parity bit
NONE, ODD, EVEN
Data bit
8 bit
Stop bit
1 or 2 bit
Baud rate
2400,4800,9600,19200,38400,57600,115200 bps
Malfunction vibration
10~55 Hz 20m / s
2
, for 10 min each in X, Y and Z directions.
Vibration resistance
10~55 Hz 20m / s
2
, for 2 hr each in X, Y and Z directions.
Malfunction shock
100m / s
2
, 3 times each in X, Y and Z directions.
Shock resistance
300m / s
2
, 3 times each in X, Y and Z directions.
Operating Environment
Temperature/Humidity
0 ~ 50°C (in the case of no freezing or condensatioin) / 20% ~ 90% RH
Storage Environment
Temperature
-25 ~ 65°C (in the case of no freezing or condensatioin)
Dimension (mm)
W40 x H107 x D43
Weight
Appox.115g
