TB9100 Calibration Software User’s Manual Index 31
Index
A
AC millivoltmeter 3
analog line, calibrating 20
audio level
calibrating
20
B
Balanced Line Calibration Wizard 20
band 1
entering 4
base station
disconnecting from
7
receive only 5
C
Calibrate Fwd/Rev Detector Bias Voltages
Wizard
26
Calibrate Output Voltage wizard 29
Calibrate PA Bias Wizard 25
Calibrate PA Power Wizard 27
Calibration and Test Unit 3
connecting up 6
calibration wizards 1
FCL Auto Tuning Wizard 15
RSSI Calibration Wizard 19
Set Exciter VCO Wizard 13, 14
Tune Receiver Front End Wizard 10, 12
Carrier Freq Offset Adjustment Wizard 22
carrier frequency, calibrating 21
COM port, selecting 5
control voltage 28
coupler fwd voltage 28
CTU
connecting up
6
E
equipment 3
tuning tool 14
exciter
adjusting lock band
13
calibrating 15, 15
component repairs to 15
F
FCL (Frequency Control Loop)
calibrating
15
FCL Calibration Wizard 16
frequency
defining range of
13
G
gate bias voltage, adjusting 25
H
hardware version
entering
4
J
Johanson 8777 tuning tool 3
L
lock band
adjusting on exciter
13
adjusting on receiver 8
log files
application errors
7
commands received and sent 7
M
module number 1
Murata tuning tool 3
P
P25 Console Gateway 5
PA
calibrating bias current
25
calibrating transmit power 26
faulty gain stage 28
low RF input power 28
viewing details of 1
PMU
calibrating output voltage
29
power supply 3
product code
entering
4
R
receive-only base station 5
receiver
