Tally Dascom 1225 - Online State

Tally Dascom 1225
16
Online State
Function Name
Switch
Operation
LED Function Description
Online {S5} L10 Toggles between Online and Offline states
Load/Eject {S4} -
 Load: Automatically loads the paper (according to path
selection) when no paper is on the platen.
 Eject: For rear tractor, it retracts the form from the
platen to allow users to install cut sheets. (NOTE:
Users have to toggle the path selection lever.)
For cut sheets, it ejects the form on the platen.
LF {S3} - Feeds a line with every press of S3.
FF [S3] -
By holding S3, the printer initially feeds a few lines; then
feeds the form to the next TOF for rear tractor or ejects
the form for cut sheets.
Tear Off {S2} L5 flashing
This is valid for tractor mode only. It feeds the form to the
tear-off position. After tearing off the form, printing starts
on the next TOF by:
 pressing S2 once, or
 receiving print data from the host.
