Tally Dascom 1225 - Offline State

Tally Dascom 1225
17
Offline State
Function Name
Switch
Operation
LED Function Description
Font {S1} L1~L4 Selects the font.
Pitch {S2} L5~L8 Selects the pitch.
LF {S3} - Feeds a line with every press of S3.
FF [S3] -
By holding S3, the printer initially feeds a few lines; then feeds
the form to the next TOF for rear tractor or ejects the form for
cut sheets.
Load/Eject {S4} -
 Load: Automatically loads the paper (according to path
selection) when no paper is on the platen.
 Eject: For rear tractor, it retracts the form from the platen to
allow users to install cut sheets. (NOTE: Users have to toggle
the path selection lever.)
For cut sheets, it ejects the form on the platen.
Online {S5} L10 Toggles between Online and Offline states
Micro Forward {S4}+[S5] - While holding down S5, press S4 to micro feed paper up.
Micro Reverse {S3}+[S5] - While holding down S5, press S3 to micro feed paper down.
Activate
user-defined
sensitivity
[S2]+{S3} Activates the calibrated PE sensor sensitivity value according
to the currently selected paper path. Beeps once when
completed.
