Talsa F14s - Page 31

HYDRAULIC PISTON FILLERS F14/25/35/50 INSTALLATION AND OPERATING MANUAL
© Talsabell s.a. All rights reserved. EN - 28 V-1.3 last revision: 07/2018
ID-code
F14s
F25s
F35s
F50s
Description
F-838
4807
4807
4807
4807
HOLDER ISOLATING BOX
F-839
0758
0758
0758
0758
ISOLATING BOX, LEGRAND 100*100*55 MM CODE 92138
4057
4057
4057
4057
ISOLATING BOX, IDE 162*116*76, POLYCARBONATE (H UL-CSA +110V)
<< F-840
aux. table
aux. table
aux. table
aux. table
CONTACTOR
F-841
4525
4525
4525
4526
CAP, KAPSTO, GPN270 REF. R6030 3
F-842
4569
4569
4569
4696
EXTENSION SWIVEL CASTOR AISI304
F-843
4404
4404
4404
4405
SWIVEL CASTER BLACK/SS WITH BRAKE
<< F-844
aux. table
aux. table
aux. table
aux. table
FAN
<< F-845
aux. table
aux. table
aux. table
aux. table
MOTORS
F-846
4559
4559
4559
4559
SILENTBLOCK SINGLE FASE MOTOR 70*30*5MM EPDM BLACK
F-847
4808
4808
4808
4808
SUPPORT MOTOR CABINET
F-848
0063
0063
0063
0063
MOTOR-PUMP COUPLING FOR FILLERS/STUFFERS
F-849
0064
0064
0064
0064
SEAL, VELLUMOID 1625-1 FOR PUMP TYPE L
F-850
4727
0037
0037
0011
GEAR PUMP 1L05IB01 R
F-851
4812
4812
4812
4812
SUPPORT OIL RESERVOIR/CABINET
F-852
4531
4531
4531
4532
INTERNAL OIL RESERVOIR, POLIPROP. WHITE
F-853
4498
4498
4498
4498
OIL CAP, DEPRESSURIZED, RED
F-854
6466
6466
6466
6466
OIL RETURN PIPE D.10 L.120 MM
F-855
6467
6467
6467
6467
OIL SUCTION PIPE D.10 L.270 MM
F-856
2290
2290
2290
4474
WHEEL, D.125 MM NYLON
F-857
DIV
DIV
DIV
DIV
CAPACITOR SINGLE PHASE MOTOR
F-858
4817
4818
4818
4819
PANEL ACCESS CABINET
F-859
6445
6445
6445
6445
ACTIVATOR KNEE LEVER D.15 L.70MM AISI303
F-860
4492
4492
4492
4492
BRASS BUSHING, B11 A-6-9-12
F-861
4489
4489
4489
4489
BRASS BUSHING, B11 B-15-20-20/25-3 WITH COLLAR
F-862
2979
2979
2979
2979
O-RING, INT. DIAM. 61*2
F-863
4729
4729
4729
4729
SUPPORT KNEE LEVER AISI304
F-864
4490
4490
4490
4490
GASKET, KNEE LEVER
F-865
6555
6555
6555
6616
KNEE LEVER, PLASTIC APM1000 BLACK
F-866
2829
2829
2829
2829
HYDRAULIC UNION, SIMPLE, GE8LR 3/8" BSP
F-867
4574
4574
4574
4574
T JOINT EVL-08 (OUTLET CONTROL TO HYDRAULIC CYLINDER + GAUGE)
F-868
4554
4554
4554
4554
HOSE, 460 MM R1T1/4 TL90HG8L-TL45HG8L, BOTTOM CYLIN-HYDR CONTROL
F-869
4556
4556
4556
4556
HOSE, PRESSURE GAUGE 1/4", LENGTH 500MM
F-870
4816
4816
4816
4816
HYDRAULIC UNION, SIMPLE MF 1/4 BSPP HF 1/4 BSPP
F-871
4555
4555
4555
4555
HOSE, 290 MM R1T1/4 ESF1/4-TL90HG8L, TOP CYLIN-HYDRAULIC CONTROL
F-872
2681
2681
2681
2681
HOSE CLAMP, MIKALOR D.12-20/9 FOR HYDR. OIL DRAIN TUBE NH
F-873
2048
2048
2048
2048
RUBBER HOSE KLEMINE-20 BAR D.12*20
F-875
2810
2810
2810
2810
NOZZLE COVER, RUBBER 12 MALE THREAD 3/8" (DRAINING HOSE)
F-878
4553
4553
4553
4815
HOSE, 720 MM R1T1/4 TL90HG8L-TL45HG8L (HYDRAULIC PUMP CONTROL)
F-879
2827
2827
2827
2827
HYDRAULIC UNION, SIMPLE, GE8LR 1/4" BSP
ID-code
F-845
Motors table
F14s
F25s
F35s
F50s
3*390/225V-50Hz
0055
0030
0030
0853
3*208V-60Hz
3333
0032
0032
0857
1*225V-50Hz
0058
0035
0035
0854
1*220V-60Hz
3334
2572
2572
0856
1*110V-60Hz
4572
3937
3937
4573
ID-code
F-844
Fan table
F14s
F25s
F35s
F50s
3*390/225V-50Hz
-
-
-
4550 /
2019
3*208V-60Hz
2019
2019
2019
2019
1*225V-50Hz
2019
2019
2019
2019
1*220V-60Hz
2019
2019
2019
2019
1*110V-60Hz
2020
2020
2020
2020
ID-code
F-840
Contactor table
F14s
F25s
F35s
F50s
3*390/225V-50Hz
2050/
2051
2050/
2051
2050/
2051
2050/
2727
3*208V-60Hz
2054
2054
2054
2439
1*225V-50Hz
2727
2727
2727
2725
1*220V-60Hz
2439
2439
2439
5045
1*110V-60Hz
3939
3939
3939
3939
