HYDRAULIC PISTON FILLERS F14/25/35/50 INSTALLATION AND OPERATING MANUAL
© Talsabell s.a. All rights reserved. EN - 27 V-1.3 last revision: 07/2018
11.2 Parts list
ID-code
F14s
F25s
F35s
F50s
Description
F-800
4561
4561
4561
4561
NOZZLE/HORN RETENTION NUT BLACK
F-801
4562
4562
4562
4562
NOZZEL/HORN POLIET. HD TRANSLUCENT D.EXT.14 INT.10L.USE 160MM (6")
4563
4563
4563
4563
NOZZEL/HORN POLIET. HD TRANSLUCENT D.EXT.20 INT.16L.USE 196MM (8")
4564
4564
4564
4564
NOZZEL/HORN POLIET. HD TRANSLUCENT D.EXT.30 INT.26L.USE 196MM (8")
F-802
6562
7861
6465
6462
S/S LID, WITHOUT ACCESSORIES
F-803
6447
6447
6447
6447
LID OPENING LEVER AISI303 (ALL STUFFERS/FILLERS FS)
F-804
4647
4647
4647
6456
BRAS BUSHING B11 A-42-54-30 LID
F-805
6450
6450
6450
6457
S/S BOLT, M39/M36 LID
F-806
4469
4469
4469
6153
BUSHING FOR LID LOCK NUT, PLASTIC APM500 BLACK
F-807
6448
6448
6448
6455
NUT FOR LID LOCK AISI303
F-808
6446
6446
6446
6446
LEVER FOR LID LOCK NUT AISI303, W/O BLACK KNOB
F-809
4229
4229
4229
4230
KNOB BLACK THREAD M10 80MM
F-810
4566
4566
4566
4566
SPANNER/WRENCH, PISTON EXTRACTOR
F-811
4472
4472
4472
4472
CSK ALLEN SCREW, S/S M16*35 DIN7991
F-812
5563
5564
5565
5566
O-RING, INT. DIAM. 345*10 RED SILICONE (1*PISTON)
F-813
6559
6452
6464
6459
PISTON, S/S, WITHOUT O-RING
F-814
4580
4497
4497
4587
O-RING, INT. DIAM. 34*2MM THREADED TIP PISTON
F-815
6560
6453
6453
6460
THREADED TIP HYDRAULIC CYLINDER BOLT AISI303
F-816
4640
4641
4641
4642
HOOD CLAMP, HYDRAULIC CYLINDER, D.198 MM NBR70
F-817
4272
4272
4272
2637
S/S HEXAGONAL SCREW, M12*35 DIN933
F-818
4522
4523
4523
4524
HYDRAULIC CYLINDER, DE0450800449G01 FILLER/STUFFER
F-819
4579
4485
4485
4586
O-RING, INT. DIAM. 165*5MM, HYDRAULIC CYLINDER
F-820
4500
4501
4502
4503
LID SEAL POLYURETHANE RED, DIAM.EXT. 404MM
F-821
6558
6451
6463
6458
FIXED DOUGH BARREL
F-822
7859
7859
7859
7859
DEPOSIT DRAINAGE PIPE D.27 L.62 GAS 3/4" AISI304
F-823
4535
4484
4694
4536
O-RING, INT. DIAM. 340*4, FLANGE DOUGH BARREL
F-824
4529
4529
4529
4529
TRANSPARENT FABRIC HOSE PVC D.32*25, DEPOSIT DRAIN
F-825
4581
4567
4567
4588
CABINET WITH ACCESSORIES
F-826
5047
5047
5047
5047
GROMMET, S-TEC 5308959 M20*1,5/13 POLIAMYDE, GREY
F-827
4645
4234
4234
4235
HANDLE M8
F-828
4528
4528
4528
4528
WALL PASS-THROUGH D.34/21,8*6MM EPDM BLACK 70 SH
F-829
6561
6454
6454
6461
THREADED ROD HYDRAULIC CONTROL M8 L=268MM AISI304
F-830
4018
4018
4018
4018
INTERNAL FORK, HYDRAULIC CONTROL ACTIVATOR, S/S
F-831
4530
4530
4530
4530
CYLINDRICAL PIN, D.6*19,5 S/S
F-832
3435
3435
3435
3435
HOLDER, MICROSWITCH DISTRIBUTOR, S/S
F-833
4726
4726
4726
4726
HYDRAULIC CONTROL 102N8SA23X-340 WITH PRESSURE KNOB
F-834
2353
2353
2353
2353
EXTERNAL PRESSURE VALVE CONTROL ASSEMBLY M1670/861, BLACK KNOB
F-835
2039
2039
2039
2039
MICRO POSITION DETECTOR, COMEPI METAL WHEEL
F-836
4466
4466
4466
4466
PRESSURE GAUGE D.63, WIKA 213.53, 0-200 BAR, THREAD 1-4"
F-837
4113
4113
4113
4114
FOOT, STAINLESS STEEL
NOTE:
The 3-digit ID code shown in the labelled
diagram are not valid for orders.
Please order parts by using only the 4-
digit code detailed in this parts list and
only through the authorized dealer who sold
the machine. Please provide the machine’s
serial number with your order.
For some parts, additional technical and
electrical drawing details will be needed.
The serial number and other relevant
information can be found on the nameplate
on the rear side of the machine head.
Enter the data of your machine here to
have them on hand in case of a
breakdown:
