Ratings
Recording media
SD card (512 MB - 2 GB) or SDHC card (4 GB - 32 GB)
File system
MTR partition: TASCAM original
FAT partition: FAT32
Built-in mic
Omni directional, 2 pcs
Audio input/output ratings
INPUT A jack
ª
XLR type (Balanced)
Connector: XLR-3-31
(1: GND, 2: HOT, 3: COLD)
Input impedance: 2.4 kΩ
Standard input level: –16 dBu
Maximum input level: 0 dBu
1/4” phone jack type (Balanced)
Connector: 6.3 mm (1/4”) TRS phone jack
(Tip: HOT, Ring: COLD, Sleeve: GND)
When INPUT A switch is set to MIC/LINE:
Input impedance: 10 kΩ or more
Standard input level: +4 dBu
Maximum input level: +24 dBu
Headroom: 20 dB
When INPUT A switch is set to GUITAR:
Input impedance: 1 MΩ
Standard input level: –2 dBV
Maximum input level: +14 dBV
Headroom: 16 dB
INPUT B jack
ª
XLR type (Balanced)
Connector: XLR-3-31
(1: GND, 2: HOT, 3: COLD)
Input impedance: 2.4 kΩ
Standard input level: –16 dBu
Maximum input level: 0 dBu
1/4” phone jack type (Balanced)
Connector: 6.3 mm (1/4”) TRS phone jack
(Tip: HOT, Ring: COLD, Sleeve: GND)
Input impedance: 10 kΩ or more
Standard input level: +4 dBu
Maximum input level: +24 dBu
Headroom: 20 dB
LINE OUT jack
ª
Connector: RCA pin jack
Standard output level: –10 dBV
Maximum output level: +6 dBV
PHONES jack
ª
Connector: 3.5 mm stereo mini jack
Maximum output level: 40 mW + 40 mW or more (THD +
N 0.1% or less, 32Ω load)
Control input/output ratings
USB jack
Connector: Mini-B type
Format: USB 2.0 HIGH SPEED, mass storage class
REMOTE jack
Connector: 2.5 mm TS jack
Audio performance
Frequency response
INPUT (MIC/LINE) → LINE OUT: 20 Hz to 20 kHz, +1 dB/
–3 dB
Distortion
INPUT (MIC/LINE) → LINE OUT: 0.01% or less
S/N ratio
INPUT (MIC/LINE) → LINE OUT: 90 dB or more
Computer requirements
See the TASCAM website for updated information about
OS compatibility.
Windows
Pentium 300 MHz or faster
128 MB or more memory
USB port (USB 2.0 recommended)
Macintosh
Power PC, iMac, G3, G4 266 MHz or faster
64 MB or more memory
USB port (USB 2.0 recommended)
Recommended USB host controller
Intel chipset
Supported OS
Windows XP, Windows Vista, Windows 7
Macintosh Mac OS X 10.2 or later
17 – Specifications
