DM-3200 Release Notes
TASCAM DM-3200 Release Notes V1.50 15
You can send MIDI Control Change messages to exter-
nal MIDI devices using the POD knobs, FADER and the
MUTE key of the DM-3200. In the default setting, they
control PAN, FADER, and MUTE respectively.
Figure 10: MIDI MIXER screen
This operation is possible only when the Layer Status is set
to REMOTE and the MIDI MIXER screen is currently show-
ing or was the last EXT.CTRL screen displayed. The screen
will show “REM PAN” for the encoder mode, and the encod-
ers will control the pan data.
When ON/OFF status is set to ON, a check mark appears
in the check box. When it is OFF, the box is blank. In the
figure 11, all the channels are set to ON.
You cannot operate the MIDI control of the channel pan
when the surround mode is not set to STEREO.
When the Layer Status is set to REMOTE the pan value
is displayed on, and can be controlled with the rotary
encoders.
Changing the assignment
You can change the MIDI channel, Control Change
number, and ON/OFF status that are assigned to each of
the POD knobs, FADER, and the MUTE key. Changes are
made on the MIDI>CTRL.CHANGE screen.
Figure 11: MIDI>CTRL.CHANGE screen
ª
To display this screen, either press the MIDI key followed
by the POD 3 key (or keep pressing the MIDI key), or move
the cursor to the (Jump to SCREEN) button at the top
right on the MIDI MIXER screen, and press the ENTER key.
Use the POD 4 knob to select the key whose assigned
function is to be changed (FADER, PAN or MUTE) in the
TARGET section on the right of the screen.
You will see a chart showing MIDI channel, Control
Change number, and ON/OFF status of the selected key
(channel 1-16) on the left of the screen.
Use the cursor key to select the item to be set, select the
value using the JOG/DATA dial, then press the ENTER
key to set the value. When you are changing the ON/OFF
status, press the ENTER key.
If there is more than one key that is assigned to the
same MIDI channel, you cannot assign the same
Control Change number to both of them.
A Control Change number can be selected from the
following: 1-5, 7-31, 64-95.
When ON/OFF status is set to ON, a check mark
appears in the check box. When it is OFF, the box is
blank. In the figure 11, all the channels are set to ON.
You cannot operate the MIDI control of the channel
pan when the surround mode is not set to STEREO.
MIDI mixer
