DM-3200 Release Notes
TASCAM DM-3200 Release Notes V1.50 7
MIDI control change message support
for mixer parameters
MIDI control change messages are now supported, allow-
ing mixer parameters (FADER, PAN, and MUTE) to be
controlled.
This allows MIDI devices to be controlled in synchroniza-
tion with operations on the DM-3200 mixer, or conversely
for mixer parameters to be controlled from a MIDI device.
In the MIDI>CtrlChg MIX. screen, the CONTROL CHANGE TABLE
FOR MIXER allows you to assign control change numbers.
Figure 8 MIDI>CtrlChg MIX screen
By using BATCH SETUP you can make settings for all
sixteen channels at once.
MIDI>SETUP screen filtering
In conjunction with MIDI control change support for mixer
parameters, filtering has been added to the USB MIDI 4:
PC/CC port.
Figure 9 MIDI>SETUP screen
Until now, the input/output on/off setting for USB MIDI port
3 (used for MIDI time code) had been a single setting for
input and out put, but these can now be set independently.
ª
ª
MIDI Device Inquiry message support
When an identity request is received from the following
MIDI ports of external device, the following message iden-
tify reply is transmitted.
F0 7E 00 06 02 4E 07 01 00 06 v1 v2 pp 00 F7
v1: Major version number of firmware
v2: Minor version number of firmware
pp: MIDI port ID
00: The DM-3200’s MIDI IN/OUT
04: USB MIDI 4: PC/CC port
05: USB MIDI 5: USB REMOTE 1 port
06: USB MIDI 6: USB REMOTE 2 port
