Tascam QUICK REFERENCE DM-3200 Release Notes

DM-3200 Release Notes
8 TASCAM DM-3200 Release Notes V1.50
Module parameter copy function
You can now copy module parameters from a module to
another module.
PARAM COPY settings
Access the UTILITY>PARAM.COPY screen. The copy opera-
tion is performed in the MODULE TO MODULE section of
this screen.
Figure 10 UTILITY>PARAM.COPY screen
1. The upper part of the MODULE PARAMETERS section
lets you copy from one module to one other module,
and the lower part lets you copy from one module
to multiple modules. Use the radio buttons to select
the desired type of copy operation.
2. Use the cursor keys to move the cursor, use the
JOG/DATA dial to select the module that you
want to copy (left side), and press the ENTER key.
Select the copy-destination module (right side) in
the same way.
3. Move the cursor to the COPY button and press the
ENTER key.
A popup message will ask you for confirmation.
4. Press the ENTER key to execute the copy.
If you decide to cancel, press any cursor key.
PASTE SAFE
In the PASTE SAFE section you can select the parameters
that will be pasted.
Parameters whose square check boxes are selected will not
be pasted.
You can copy/paste from a CHANNEL to a master module
such as a BUSS or AUX, or the reverse. In this case,
parameters existing at the copy-source but not the copy-
destination will not be copied; they will retain their state
from before the paste operation. The same applies to
parameters that don't exist in the copy-source but do exist
at the copy-destination.
ª
The
–
symbols at the right indicate parameters that exist in
the corresponding modules.
NOTE
Module functions include some parameters not shown
in this list, such as DIGITAL TRIM, but parameters not
shown in the list will not be copied/pasted.
BUSS pan mode batch setup
In the ASSIGN>BUSS screen, BUSS PAN MODE BATCH SETUP
has been added to allow one-step setup of BUSS pan mode.
Figure 11 ASSIGN>BUSS screen
1. Move the cursor, use MODULE to select the channel,
use TARGET to select the busses whose pan mode
you want to change, and use ON/OFF to specify the
on/off setting.
2. Move the cursor to the SET button and press the
ENTER key.
A popup message will ask you for confirmation.
3. Press the ENTER key to execute the copy.
If you decide to cancel, press any cursor key.
ª
Operation

Tascam QUICK REFERENCE DM-3200 Specifications

General

Type	Digital Mixer
Channels	32
Motorized Faders	Yes
Inputs - Mic Preamps	16
Aux Sends	8
MIDI I/O	Yes
Phantom Power	Yes
Word Clock	Yes
Outputs - Digital	AES/EBU, S/PDIF
EQ Bands	4-band
Digital I/O	TDIF, ADAT
USB	Yes
FireWire	Optional (with expansion card)
Outputs - Main	2 (XLR)
