10. LED DESCRIPTION ON THE BOARD
DL4 DL5 DL6 DL7 DL8 DL9
DL2
ABBRE-
VIATIONS
DESCRIPTION STATE
DL2 Low voltage presence led ON
DL4 Displays the status of the START input OFF
DL5 Displays the status of the PEDESTRIAN OFF
DL6 Displays the status of the PHOTOCELLS ON
DL7 Displays the status of the STOP input ON
DL8 Displays the status of the opening limit switch ON
DL9 Displays the status of the closing limit switch ON
11. DIP SWITCH DESCRIPTION
1 AUTO LOCK
On
when opening is complete, the closure of the automation is automatic
after the time set during programming has elapsed.
O closing requires a manual command.
DIP 2 DIP 3 FUNZIONE
On On
In OPENING: ignore the START command
In CLOSING: START command reverses direction and reopens
On O
In OPENING: sequence of commands OPENING-STOP-CLOSING
In CLOSING: START command reverses direction and reopens
O On
In OPENING: ignore the START command
In CLOSING: sequence of commands CLOSING-STOP-OPENING
O O
In OPENING: sequence of commands OPENING-STOP-CLOSING
In CLOSING: sequence of commands CLOSING-STOP-OPENING
4 NOT USED
On not used.
O not used
