The following routine work must be done in the specied time intervals:
Part Weekly Monthly 2x annually Annually
Display console c I
Belt tension
I
Belt lubrication
I
Plastic covers
c I
Screws & cable connections
I
Legends: C = cleaning; I = inspect
3 ASSEMBLY
3.1 Package contents
The package contains the parts represented in the illustration, including a power
cable with mains plug. If one of the illustrated parts is missing, please contact your
contract partner.
Part Description Qty.
A Console 1
B
Frame 1
C
Handrail (left) 1
D
Handrail (right) 1
E
Console mast (left) 1
F
Console mast (right) 1
G
Cover (left) 1
H
Cover (right) 1
I
Bottle 1
A
B
C
D
E
F
I
G
H
