55
9.3 Parts list
No Qty. Part number Description
1 1 HTF236P-D5 console set
2 1 P-3534 console upper cover
3 10 SOC8 nylon nut M8xP1.25
4 1 P-3544 iPad holder
5 2 SAA5-15 round head Philips screw M5xP0.8x15
6 2 SOI5 nut M5X25X13
7 1 XEK-248 Bluetooth module
8 1 XRA-179-003 console board (LCD with BT module)
9 1 XEM-016 safety key switch set
10 1 1XEK-247 keyboard
12 1 P-3535 console lower cover
13 1 P-3540L handrail upper cover left
14 1 P-3541L handrail lower cover left
15
2 A1A094E0505-001 handrail tube
4 SOF8A hex nut M8XP1.25
16 1 P-3540R handrail upper cover right
17 1 RCA-004 console overlay decal
18 1 P-3541R handrail lower cover right
19 4 NO-4994 hand pulse sensor plate
20 2 P-3542 hand pulse plastic base
21 2 P-3543 rocking bar switch cover
22 4 NS-266 compressed spring
23 2
XL-1293B handrail switch with hand pulse wire-lower
XEK-249 handrial keyboard
24 1 RBA-043 handrail sticker-incline
25 1 RBA-042 handrail sticker-speed
26 24 SAK3-8 round head Philips self-tapping screw ø3x8
27 4 SAI3-8 round head Philips self-tapping screw ø3x8
28 30 SCI4-16 truss head Philips self-tapping screw ø4x16
29 1 XL-874A control wire-upper
30 1 XL-1084A hand pulse wire-upper
