1-2
TO THE INSTALLER
Model 104
To the Installer
1
Air-Cooled Machines
Do not obstruct air intake and discharge openings.
Air-cooled machines require a minimum of 6 in. (152 mm)
of clearance around all sides of the freezer to allow for
adequate air flow across the condenser(s). Failure to
allow adequate clearance can reduce the refrigeration
capacity of the freezer and possibly cause permanent
damage to the compressor.
Electrical Connections
In the United States, this equipment is intended to be
installed in accordance with the National Electrical Code
(NEC), ANSI/NFPA 70-1987. The purpose of the NEC
code is the practical safeguarding of persons and
property from hazards arising from the use of electricity.
This code contains provisions considered necessary for
safety. In all other areas of the world, equipment should
be installed in accordance with the existing local codes.
Contact your local authorities.
Each machine requires one power supply for each data
label on the machine. Check the data label on the freezer
for branch circuit over current protection or fuse, circuit
ampacity and other electrical specifications. Refer to the
wiring diagram provided inside of the electrical box for
proper power connections.
WARNING! This machine must be properly
grounded. Failure to do so can result in severe personal
injury from electrical shock.
IMPORTANT! An equipotential grounding lug is
provided with this machine. Some countries require the
grounding lug to be properly attached to the rear of the
frame by the authorized installer. The installation location
is marked by the equipotential bonding symbol (5021 of
IEC 60417-1) on both the removable panel and the
machine's frame.
IMPORTANT!
• Stationary machines which are not equipped
with a power cord and a plug or another device
to disconnect the machine from the power
source must have an all-pole disconnecting
device with a contact gap of at least 0.125 in.

(3 mm) installed in the external installation.
• Machines that are permanently connected to
fixed wiring and for which leakage currents may
exceed 10 mA, particularly when disconnected
or not used for long periods, or during initial
installation, shall have protective devices, to
protect against the leakage of current such as a
GFI, installed by the authorized personnel to the
local codes.
• Supply cords used with this machine shall be

oil-resistant, sheathed flexible cable not lighter
than ordinary polychloroprene or other
equivalent synthetic elastomer-sheathed cord
(code designation 60245 IEC 57) installed with
the proper cord anchorage to relieve conductors
from strain, including twisting, at the terminals
and protect the insulation of the conductors from
abrasion.
• If the supply cord is damaged, it must be
replaced by a Taylor service technician in order
to avoid a hazard.
• Secure the supply cord ground lead to the
machine in a location where if the cord is pulled,
the main power leads will become taut before
the ground lead can break loose.
60-Cycle Machines
This equipment is supplied with a three-wire cord and
grounding type of plug, for connection to a single-phase,
60-cycle, branch circuit supply. This machine must be
plugged into a properly grounded receptacle. Permanent
wiring may be employed if required by local codes.
Instructions for conversion to permanent wiring are as
follows.
1. Make sure the freezer is electrically disconnected.
2. Remove the rear panel and locate the small electrical
box at the base of the freezer.
3. Remove the factory-installed cord and strain-relief
bushing.
!
FOLLOW YOUR LOCAL ELECTRICAL CODES.
