6-4
OPERATING PROCEDURES
Model 104
Operating Procedures
6
15. Secure the freezer door hinge by installing the pivot
pin.
Figure 6-15
16. Slide the drip pan into the hole in the front panel.
Figure 6-16
Sanitizing
1. Prepare 2 qt. (1.9 L) of an approved 100 ppm
sanitizing solution (for example, Stera-Sheen
®
).
Use warm water and follow the manufacturer’s
specifications.
2. Open the mix inlet cover on top of the freezer.
Figure 6-17
Note: Sanitize your hands and the funnel.
3. Install the funnel into the mix inlet hole on top of the
freezer.
Figure 6-18
4. Pour the sanitizing solution into the funnel and allow
the solution to flow into the freezing cylinder.
Figure 6-19
10283
