Taylor 220 Service Manual

+ Available Separately
50
Parts List Models 104 & 220
Model 220 -- HP62 -- J5083472/Up
DESCRIPTION
PART
NUMBER
220
QTY.
W ARR.
CLASS
REMARKS PARTS
UPDATE
BAR-CROSS *220* 011740 1 103
+PIN A.-CROSSBAR HINGE X04329 2 103
BEARING-REAR SHELL *NICK.PLATE 031324 1 000
+GUIDE-DRIP SEAL 028992 1 000 +NUT-BRASS BEARING 028991 1 000 +WASHER-BEARING LOCK 012864 1 000
BEATER A.-NEW STYLE 220* X32269 1 103
+BLADE-SCRAPER *220* PLASTIC 052586 3 000 (OLD METAL - X07892)
BELT-V-4L400 007590 2 000 BLOCK-TERMINAL 2P-L1,L2 039422 1 103 208-230/60/1 BLOCK-TERMINAL 3P-L1,L2,L3 039423 1 103 208-230/60/3 BLOWER A.-HIGH OUTPUT X53478-27 1 103 J9113948/ UP
BOOT-CAPACITOR INSULATING 031314 1 000 BRACKET-CAPACITOR 1-1/4X2-1/16 031205 1 103 CAPACITOR-RUN- 10 UF/370V 033047 1 103 CLIP-SCREEN-BLOWER 053730 4 103 HOUSING-BLOWER-4 POLE 053727 1 103 MOTOR-FAN 208-240V 50/60HZ 053480-27 1 103 SCREEN-BLOWER 053729 1 103 WHEEL-BLOWER 053726 1 103
BLOWER A. X47833-27 1 103 PRIOR TO J9113948 - REPLACE WITH X53478-27
BOOT-CAPACITOR INSULATING 031314 1 000 CAPACITOR-RUN- 10 UF/370V 033047 1 103 HOUSING A.-W/WHEEL X30160 1 103 208-20/60/1 MOTOR-BLOWER-208/230V 50/60 HZ 046536-27 1 103
BRUSH-DRAW VALVE 1-1/2”OD X 3” 014753 1 000 BRUSH-MIX PUMP BODY-3”X7”WHITE 023316 1 000 BRUSH-REAR BRG 1IN.DX2IN.LGX14 013071 1 000 BUZZER 022758-27 1 103 CAP-RUBBER MOUNT 011844 2 103 CASTER-LOCKING SWIVEL 3 IN. 030307 2 103 FRONT CASTER-SWV-3/4-10 ST. 3IN WHL 021279 2 103 REAR COLLAR-HOLDING 019481 6 103 COMPRESSOR - CS27K3E-PFV-238 053465- 1 512 J9066689/UP 145
