Taylor 220 Service Manual

51
+ Available Separately
Models 104 & 220 Parts List
DESCRIPTION PARTS
UPDATE
REMARKSW ARR.
CLASS
220
QTY.
PART
NUMBER
+CAPACITOR-RUN- 40MF/440VOLT 036049 1 103 208-20/60/1 +CAPACITOR-START-189-227UF/330V 033044-1 1 103 208-20/60/1 +RELAY-START-COMPRESSOR 053473 1 103
COMPRESSOR L63A183BBCA - BRISTOL 048741- 1 512 Prior to J9066689 145
+CAPACITOR-RUN- 35UF/440V 048132 1 103 208-230/60/1 +CAPACITOR-START-216-259UF/330V 048908 1 103 208-230/60/1 +RELAY-START-COMPRESSOR 048909 1 103 208-230/60/1
CONDENSER-AC-12LX18HX4.3-5ROW 019558 1 103 CONTROL-TEMP -15F TO 40F 019747 1 103
+KNOB-TEMP CONTROL 013731 1 103
COUPLING-DRIVE 3/4 HEX X 1-7/8 012721 1 103
+SCREW-5/16-18 X 5/16 ALLEN SET 042511 2 000
COVER A.-HOPPER-110-220 X24778-SER 1 103
+GASKET-HOPPER COVER-10 QT 011412 1 000
KNOB-MIX COVER 025429 1 103
DECAL-CLEAN INST.-BATCH 030582 1 000 DECAL-DEC-TAYLOR 021872 1 000 DECAL-TROUBLESHOOTING 038374 1 000 DIAGRAM-WIRING *110-220* 030385 1 000 DOOR A.-PARTIAL *220* SPOUT X32938 1 103 W/CHUTE & INTERLOCK
+BEARING-FRONT *110-220* 019176 1 000 +CAP A.-COVER *220* X29667 1 103 +HOLDER A.-BEARING *121 W/SPOUT X30078 1 103
+O-RING-5/8 OD X.139W 026020 1 000
+O-RING-11-3/8 OD X .103W 019046 1 000 +O-RING-2-1/8 OD X .139W-#225 020051 2 000 +PIN A.-PIVOT X34737 2 103 +PISTON-VALVE *121 W/SPOUT* 030083 1 103 +ROD A.-DRAW *121 W/SPOUT* X30079 1 103
DRYER-FILTER 3/8 X 3/8SOL HP62 049154 1 000 FUNNEL A.-MIX *220* X35636 1 103
+O-RING-1-7/8 OD X .139W 018564 1 000 REPLACES 011471 145
FUNNEL-PLASTIC DOOR 029670 1 000 GEAR A.*REDUCER 021286 1 212 GUIDE A.-DRIP PAN X28863 1 103
Model 220

Taylor 220 Specifications

General

Brand	Taylor
Model	220
Category	Freezer
Language	English
