Introduction
Model 430
081202
Electrical Connections
In the United States, this equipment is
intended to be installed in accordance with the
National Electrical Code (NEC), ANSI/NFPA 70-1987.
The purpose of the NEC code is the practical
safeguarding of persons and property from hazards
arising from the use of electricity. This code contains
provisions considered necessary for safety.
In all other areas of the world, equipment should be
installed in accordance with the existing local codes.
Please contact your local authorities.
Each unit requires one power supply for each data
label on the unit. Check the data label on the unit for
fuse, circuit ampacity and other electrical
specifications.
Refer to the wiring diagram provided inside of the
electrical box for proper power connections.
FOLLOW YOUR LOCAL ELECTRICAL CODES!
CAUTION: THIS EQUIPMENT MUST BE
PROPERLY GROUNDED! FAILURE TO DO SO
CAN RESULT IN SEVERE PERSONAL INJURY
FROM ELECTRICAL SHOCK!
Note: This unit is provided with an equipotential
grounding lug that is to be properly attached to either
the rear of the frame or the under side of the base pan
near the entry hole for incoming power, by the
authorized installer. The installation location is marked
by the equipotential bonding symbol (5021 of IEC
60417-1) on both the removable panel and the
equipment’s frame, as well as on the diagram.
S DO NOT operate the freezer with larger
fuses than specified on the data label.
S Stationary appliances which are not
equipped with a power cord and a plug or
another device to disconnect the appliance
from the power source must have an all-pole
disconnecting device with a contact gap of
at least 3mm installed in the external install-
ation.
S Appliances that are permanently connected
to fixed wiring and for which leakage cur-
rents may exceed 10 mA, particularly when
disconnected or not used for long periods,
or during initial installation, shall have pro-
tective devices such as a GFI, to protect
against the leakage of current, installed by
the authorized personnel to the local codes.
S Supply cords used with this unit shall be
oil-resistant, sheathed flexible cable not
lighter than ordinary polychloroprene or oth-
er equivalent synthetic elastomer-sheathed
cord (Code designation 60245 IEC 57) in-
stalled with the proper cord anchorage to
relieve conductors from strain, including
twisting, at the terminals and protect the in-
sulation of the conductors from abrasion.
Failure to follow these instructions may result in
electrocution or damage to the machine.
Beater Rotation
Beater rotation must be clockwise as viewed
looking into the freezing cylinder.
The following repairs must be performed by an
authorized Taylor Service Technician.
Disconnect all power to the unit. Failure to
follow this instruction may result in electrocution.
To correct rotation on a single-phase unit, change the
leads inside the beater motor by following the diagram
printed on the motor label.
