Model 430
Systems and Controls
Thermistor Curve
F. C. K OHM F. C. K OHM F. C. K OHM
-10 -23.3 118.201 22 -5.5 43.530 54 12.2 17.915
-9 -22.7 114.394 23 -5.0 42.340 55 12.7 17.451
-8 -22.2 110.709 24 -4.4 41.136 56 13.3 16.998
-7 -21.6 107.143 25 -3.8 39.967 57 13.8 16.557
-6 -21.1 103.692 26 -3.3 38.830 58 14.4 16.128
-5 -20.5 100.352 27 -2.7 37.727 59 15.0 15.710
-4 -20.0 97.120 28 -2.2 36.654 60 15.5 15.315
-3 -19.4 94.085 29 -1.6 35.612 61 16.1 14.929
-2 -18.8 91.144 30 -1.1 34.599 62 16.6 14.554
-1 -18.3 88.296 31 -0.5 33.616 63 17.2 14.187
0 -17.7 85.536 32 0 32.660 64 17.7 13.830
1 -17.2 82.863 33 0.5 31.760 65 18.3 13.482
2 -16.6 80.273 34 1.1 30.885 66 18.8 13.143
3 -16.1 77.765 35 1.6 30.035 67 19.4 12.812
4 -15.5 75.334 36 2.2 29.207 68 20.0 12.490
5 -15.0 72.980 37 2.7 28.403 69 20.5 12.185
6 -14.4 70.627 38 3.3 27.620 70 21.1 11.888
7 -13.8 68.350 39 3.8 26.859 71 21.6 11.598
8 -13.3 66.147 40 4.4 26.120 72 22.2 11.315
9 -12.7 64.014 41 5.0 25.400 73 22.7 11.039
10 -12.2 61.951 42 5.5 24.721 74 23.3 10.769
11 -11.6 59.953 43 6.1 24.059 75 23.8 10.507
12 -11.1 58.021 44 6.6 23.416 76 24.4 10.250
13 -10.5 56.150 45 7.2 22.789 77 25.0 10.000
14 -10.0 54.340 46 7.7 22.180 78 25.5 9.763
15 -9.4 52.854 47 8.3 21.586 79 26.1 9.532
16 -8.8 51.409 48 8.8 21.009 80 26.6 9.306
17 -8.3 50.003 49 9.4 20.447 81 27.2 9.085
18 -7.7 48.636 50 10.0 19.900 82 27.7 8.870
19 -7.2 47.306 51 10.5 19.384 83 28.3 8.659
20 -6.6 46.012 52 11.1 18.881 84 28.8 8.454
21 -6.1 44.754 53 11.6 18.392 85 29.4 8.254
When checking a thermistor probe, first determine the temperature at the probe and find it on this chart, along with
the correct ohmmeter reading. If your ohmmeter reading varies from the correct reading, determine whether the
difference is acceptable. If a probe is faulty, the difference will be great.
