4
Introduction
Model 430
150210
Model 430 Specifications
Freezing Cylinder
One, 4 quart (3.8 liter) capacity.
Mix Hopper
One, 14 quart (13.2 liter) capacity.
Refrigerated and insulated.
Beater Motor
One, .25 hp. motor.
Refrigeration Unit
One, approximately 4,000 btu/hr compressor.
Refrigerant 404A.
Electrical
Standard is 115/60/1. This equipment is supplied with
a 3-wire cord and grounding type plug, for connection
to a single phase, 60 cycle, branch circuit supply. This
unit must be plugged into a properly grounded
receptacle. The cord and plug provided are 20 amp. for
115/60/1, or 15 amp. 208-230/60/1. Therefore, the wall
outlet must also be 20 amp. for 115/60/1 or 15 amp. for
208-230/60/1. For exact electrical information, always
refer to the data label of the unit.
Air Cooled
Clearance: 3” (76.2 mm) around all sides.
Water Cooled
The water inlet and drain connections are located in
the rear panel (3/8” FTP / 9.5 mm).
Dimensions
Width: 16-7/16” (418 mm).
Depth: 28-3/4” (730 mm).
Height: 27-1/2” (699 mm).
Floor Clearance: Designed to rest on a plastic pad
directly on a counter top.
Approximate Weights
Net: 176 lbs. (79.8 kgs.).
Crated: 215 lbs. (97.5 kgs), 14.5 cu. ft. (.40 cu. m.).
Specifications are subject to change without notice.
This unit is designed and constructed to meet stringent
safety and sanitation requirements for NSF, UL, and
CSA.
