Taylor 430 Service Manual

Parts List
39
+ Available Separately
Model 430 Parts List
151005
430 Torque
DESCRIPTION PART
NUMBER
QTY. WARR.
CLASS
REMARKS
043012H555 TORQUE - 115V 60HZ 1PH & 043027H555 TORQUE - 208-230V 60HZ 1PH
ACCUMULATOR-COPPER 2"DIAX10" 068069 1 103
ARM-TORQUE CONTROL 051325 1 103
+BUSHING-ARM-TORQUE 049737 1 103
BEARING-FRONT 013116 1 000
BEARING-GUIDE 014496 1 000
BEARING-REAR SHELL *PLASTIC* 032511 1 000
+GUIDE-DRIP SEAL 028992 1 000
+NUT-BEARING 028991 1 000
+WASHER-BEARING LOCK 012864 1 000
BEATER A.-4QT-1 PIN-SUPPORT X49490 1 103
+BLADE-SCRAPER-PLASTIC 9-13/16L 046237 1 000
+CLIP-SCRAPER BLADE*8.75 INCH* 046238 1 103
BELT-V-4L350 004194 1 000 J7050000/UP (Replaces 004227)
BLOCK-TERMINAL 4 POLE GREEN 080967 1 103 REPLACED 024156
BLOCK-TERMINAL 3 POLE GREEN 080968 1 103 REPLACED 024156
PLATE-END TERMINAL BLOCK 080969 2 103 REPLACED 024156
BRUSH-REAR BRG 1IN.DX2IN.LGX14 013071 1 000
BRUSH-DOUBLE ENDED-PUMP & FEED TUBE 013072 1 000
BRUSH-DRAW VALVE 1-1/2"OD X 3" 014753 1 000
BRUSH-MIX PUMP BODY-3"X7"WHITE 023316 1 000
COMPRESSOR AKA9462ZXA-AK172AT (TECUMSEH) 049302-12 1 512 115V 60HZ 1PH
+CAPACITOR-RUN- 25UF/370VAC 023739 1 103 115V 60HZ 1PH
+CAPACITOR-START- 72-88UF/250V 039557-27 1 103 115V 60HZ 1PH
+RELAY-START-COMPRESSOR 045432-12 1 103 115V 60HZ 1PH
COMPRESSOR AKA9462ZXD-AK172ET (TECUMSEH) 049302-27 1 512 208-230V 60HZ 1PH
+CAPACITOR-RUN- 15UF/370V 027087 1 103 208-230V 60HZ 1PH
+CAPACITOR-START- 72-88UF/330V 039567 1 103 208-230V 60HZ 1PH
430 Torque

Taylor 430 Specifications

General

Weight	Unknown
Freezing Capacity	Unknown
Production Capacity	Unknown
Mix Hopper Capacity	Unknown
Dimensions	Unknown
Electrical	Unknown
Capacity	Unknown
Temperature Range	Unknown
Defrost Type	Unknown
Power Source	Unknown
Dimensions (H x W x D)	59.5" (1511 mm) x 21" (534 mm) x 31.5" (800 mm)
