Model 339 Exploded View
ITEM DESCRIPTION PART NO.
1 SHELL A.-INSULATED X50770
1a BEARING-REAR SHELL 031324
1b WASHER-BEARING LOCK 012864
1c NUT-BRASS BEARING 028991
1d GUIDE-DRIP SEAL 028992
2 COUPLING-DRIVE 3/4 HEX 012721
3 GEAR A.-REDUCER 4.21:1 021286
4 PULLEY-2AK64-5/8 BORE 039695
5 SCREW-5/16-18 X 3-1/4 STL 022678
6 BELT-AX33 024396
7 PULLEY-2AK20 X 5/8 BORE 034238
8 MOTOR-1.0 HP 013102-
9 GROMMET-7/16X5/16 016212
10 SPRING-COMP.970X. 115X2.00 025707
11 CAP-RUBBER MOUNT 011844
12 CLAMP-MOUNTING 012257
13 BUSHING-MTG. RUBBER 012258
14 HINGE A.-MOTOR X25731
15 MOTOR-FAN 105CFM 027309-27
16 SHROUD-DANFOSS 027386
17 CONDENSER-AC-7X6X1.25 027155
18 DRYER-CAP. TUBE .026 ID 047699
19 GUIDE A.-DRIP PAN X28699
20 BLOWER A. X47833-
21 SHROUD-CONDENSER REAR 046575
22 SHROUD-CONDENSER TOP 046576
23 SHROUD-CONDENSER FRT. 046574
24 CONDENSER-AC-12LX18H 048233
ITEM
DESCRIPTION
PART NO.
25 VALVE-EXP-AUTO-1/4S 047232
26 DRYER-FILTER-HP62-3/8 048901
27 ADAPTOR A.-CASTER X18915
28 CASTER-SWV 5/8 STEM 4IN 018794
29 BOARD-LOGIC-GEN 2.6-SD X36641SER1
30 COMPRESSOR CS14K63-PFV 052396-
31 KIT-MOUNTING-COMP. 052197
32 SWITCH A.-DRAW SELF X38547
CLOSING
33 VALVE-ACCESS-1/4 MFL 047016
34 SWITCH-PRESSURE 405 PSI 052663
35 VALVE-ACCESS 1/4FL X 3/8 043232
36 COMPRESSOR TL3G-R134A 047701-
36a RELAY-START-COMPRESSOR 047702-27
37 CAPACITOR-START-60UF 047703
38 STUD-NOSE CONE 022822
39 KIT-MOUNTING-COMP. 047704
40 VALVE-EPR 1/4S 022665
41 VALVE-ACCESS 1/4FL 044404
42 CONTROL A. SEE PG. 68
43 COVER-CONTROL BOX 024440
44 BOX A.-CAP & RELAY SEE PG. 77
45 SPACER-PROBE SO. HOLE 030966
46 DISC-PROBE SQUARE HOLE 030965
47 PROBE A.-MIX SQUARE X30922
48 PANEL A.-FRONT X32956
49 BOLT-CARRIAGE 1/4-20 X 3/4 012347
50 SWITCH-TOGGLE^PDT 037394
* DEFLECTOR-BLOWER 046586
*NOT SHOWN
