Taylor 8751 User Manual

Box A.-Cap & Relay - X48535-27
208-230/60/1
ITEM DESCRIPTION PART NO.
1 SCREW-8-32 X 1/4 RHM 000953
2 CONNECTOR-BX 3/8 STR 014569
3 SLEEVE-WIRE 1/2 I.D. X .031 022175 5 -1
4 CONNECTOR-BX 3/8 90DEG 001793
5 SLEEVE-WIRE 1/2 I.D. X .031 022175 4 -2
6 SCREW-10X3/8 TYPE B 015582
ITEM DESCRIPTION PART NO.
7 STRAP-CAPACITOR 5-5/8 IN. 030258
8 CAPACITOR-RUN- 20UF/440V 012906
9 CAPACITOR-START-161 -193UF 031790
10 BOX-CAPACITOR RELAY 030183
11 RELAY-START-COMPRESSOR 038145
*12 COVER-CAP.RELAY BOX 030315
*NOT SHOWN
