Taylor 8751 User Manual

Air/Mix Pump-Soft Serve X45316-B
ITEM DESCRIPTION PART NO.
1 TUBE A.-MIX INLET X45318
2 SEAL-AIR INLET FITTING 045327
3 O-RING-3/40DX.103W 015835
4 SPRING-TAPERED 1-7/8L 022456
5 POPPET-RUBBER-BLACK 022473
6 BODY A.-COAX VALVE X46860-B
7 O-RING-2-1/8 OD X .139W-#225 020051
8 O-RING-1-3/8 OD X .103W-#123 018664
9 RING-CHECK 2 IN ODX 1/2 020050
10 RING-CHECK 1-1/4 OD X 3/8 033215
11 PISTON-COAX PUMP *B*HPR 045319-B
12 PIN A.-COAX PUMP *HT*SS* X36950
ITEM DESCRIPTION PART NO.
13 CYLINDER A.-PUMP X44755
14 CLIP-MIX PUMP RETAINER 044641
15 SHAFT A.-DRIVE-MIX PUMP X39084
15a SHAFT-PUMP-MIX 039106
15b CRANK-DRIVE 039235
15c O-RING1/2IDX.139W 048632
15d O-RING 1-3/40DX.139W 008904
16 PIN-COTTER-HAIRPIN-1/8DIA 044731
17 TUBE A.-PUMP FEED SS (8751) X44666
*17a TUBE A.-PUMP FEED L (8754) X44662
*17b TUBE A.-PUMP FEED R (8754) X44664
18 O-RING-11/16 OD x .103 W RED 016132
*NOT SHOWN

Taylor 8751 Specifications

General

Brand	Taylor
Model	8751
Category	Ice Cream Maker
Language	English
