Taylor 8751 User Manual

Control A. - X42603-27A (Model 774)
208-230/60/1
ITEM DESCRIPTION PART NO.
1 RELAY-3 POLE-20A-208/240 012725-33
2 STARTER-1 PHASE-4.5 TO 7 041950-27K
3 BOARD-POWER-GEN 1 &2 X32326-SER
*3a FUSE-SLO BLO 051272
4 SCREW-6-32X5/8 TAPTITE 041250
5 SCREW-8X1/4 SL HEX HD B 009894
6 LABEL-GROUNDING 017669
7 LUG-GROUNDING 020928
8 SCREW-10-32X1/2 MF HEX 020982
9 NUT-10-32 MF LOCK 020983
ITEM DESCRIPTION PART NO.
10 SCREW-8 X1 -1/4 RDHD 039420
BLOCK-TERMINAL 2P-L1, L2 039422
11
BLOCK-TERMINAL 3P-L1,2,3 039423
12 CONNECTOR-BX 3/8 ST R 014569
13 BUSHING-SNAP 11/16ID 010548
14 BUSHING-SPLIT 43/64ID 027691
15 RELAY-SPDT-30 A-240 V 032607 7 -2
16 BOX A.-CONTROL X32958
17 LABEL-COPPER COND ONLY 025948
*NOT SHOWN
