Taylor 8751 User Manual

Control A. - X52614-27 (Model 750)
208-230/60/1
ITEM DESCRIPTION PART NO.
1 STRAP-CAPACITOR 037890
2 SCREW-10 X 3/8 TYPE B-HEX 015582
3 RELAY-START-COMPRESSOR 051957 7 -2
4 CAPACITOR-RUN 20 UF/440 V 012906
5 BLOCK-TERMINAL 2P-L1.L 2 039422
6 SCREW-8X1/4 SL HEX HD 009894
7 CAPACITOR-START-18 -227UF 9 033044 -1
8 LUG-GROUNDING 260 020928
9 SCREW-10-32X1/2 MF HEX 020982
10 NUT-10-32 MF LOCK 020983
ITEM DESCRIPTION PART NO.
11 RELAY-3 POLE-20A-208/240 5 0 012725-33
12 STARTER-1 PHASED.5 TO 7 A 041950 7K -2
13 BUSHING-SPLIT 43/64ID 027691
14 SCREW-6-32X5 TAPTITE /8 041363
15 BOX-CONTROL 050735
16 BOARD-POWER-GEN 1 & 2 X32326-SER
*16a FUSE-SLO BLO 051272
17 LABEL-GROUNDING SYMBOL 017669
18 SCREW-8 X 1-1/4 RD HD TYP B 039420
*NOT SHOWN

Taylor 8751 Specifications

General

Brand	Taylor
Model	8751
Category	Ice Cream Maker
Language	English
