Model 750 Exploded View
ITEM DESCRIPTION PART NO.
1 SHELL A.-INSULATED X50745
-la BEARING-REAR SHELL 031324
1b WASHER-BEARING LOCK 012864
1c NUT-BRASS BEARING 028991
1d GUIDE-DRIP SEAL 028992
2 COUPLING-DRIVE 3/4 HEX 012721
3 GEAR A*REDUCER 4.21:1 021286
4 SCREW-5/16-18X3-1/4 STL 022678
5 PULLEY-2AK74-5/8 027822
6 BELT-AX40 023875
7 MOTOR-1.5 HP 021522-
8 PULLEY-2AK22 X .625-.6265 016403
9 HINGE A.-MOTOR X25796
10 VALVE-EPR 1/4 022665
11 VALVE-ACCESS 1/4FL X 1/4 044404
12 VALVE-ACCESS-1/4 MFLX1/4 047016
13 COMPRESSOR TL3G-R134A 047701-
13a RELAY-START-COMPRESSOR 047702-27
14 MOTOR-FAN 105CFM 027309-
15 CAPACITOR-START-60UF 047703
16 CONDENSER-AC-7X6X1.25 027155
17 DRYER-CAP. TUBE .026 ID 047699
18 SHROUD-DANFOSS 027386
19 GUARD-FAN 028534-1
20 LEG-4" SS-W/0-RING 013458
21 STUD-NOSE CONE 022822
22 GUIDE A.-DRIP PAN X50752
23 CONTROL A. SEE PG. 70
24 PROBE A.-MIX *SQUARE X30922
ITEM DESCRIPTION PART NO.
25 DISC-PROBE *SQ HOLE 030965
26 SPACER-PROBE *SQ HOLE 030966
27 BUSHING-MT RUBBER 012258
28 MOTOR-FAN 80W 051744-27
29 CAPACITOR-RUN 4UF-440V 051785
30 BOOT-CAPACITOR INSUL. 031314
31 BRACKET-CAPACITOR 031205
32 BRACKET-FAN 038641
33 VALVE-EXP-AUTO-1/4S X 1/4 046365
34 DRYER-FILTER-HP62-3/8 X 1/4 048901
35 SHROUD-FAN 050738
36 FAN-5 BLADE 12" PUSH 32° 047279
37 CONDENSER-AC-15LX14H 046558
38 KIT-MTG.-COMPRESSOR 052196
39 CLAMP-MOUNTING 012257
40 COMPRESSOR RS80C1E-CAV 051858-
41 SWITCH-PRESSURE 405 PSI 052663
42 LINEA.-ACCESS X42513
43 PANEL A.-FRONT X50754
44 BOLT-CARRIAGE 1/4-20 X 3/4 012347
45 SWITCH-TOGGLE-DPDT 024295
46 SWITCH A.-DRAW X33322-SP
47 BOARD-LOGIC-GEN 2.6-SD X36641SER1
48 COVER-CONTROL BOX 050756
49 KIT-MOUNTING COMP. 047704
50 GROMMET-7/16X5/16 016212
51 CAP-RUBBER MOUNT 011844
52 SPRING-COMP .970x.115x2.0 025707
