Model 751 Exploded View
ITEM DESCRIPTION PART NO.
1 SHELL A.-INSULATED X49785
1a BEARING-REAR SHELL 031324
1b CONE-NOSE N/A
1c WASHER-BEARING LOCK 012864
1d NUT-BRASS BEARING 028991
1e GUIDE-DRIP SEAL 028992
2 COUPLING-DRIVE 3/4 HEX 012721
3 GEAR A.*REDUCER 4.21:1 021286
4 SCREW-6X3/8 SL HEX W HD 001825
5 PULLEY-2AK74-5/8 027822
6 BELT-AX35 022848
7 STUD-NOSE CONE 022822
8 PROBE A.-MIX SQUARE X30922
9 DISC-PROBE *SQ HOLE* 030965
10 SPACER-PROBE *SQ HOLE* 030966
11 MOTOR-1.5 HP 021522-
12 CLAMP-MOUNTING 012257
13 BUSHING-MOUNTING 012258
RUBBER
14 PULLEY-2AK22 X .625-.6265 016403
15 HINGE A.-MOTOR X25731
16 GROMMET-7/16X5/16 016212
17 SPRING-COMP.970X.115X2.00 025707
18 CAP-RUBBER MOUNT 011844
19 DRYER-FILTER-HP62-3/8 048901
20 VALVE-EXP-AUTO-1/4 S X 1/4 046365
21 SWITCH-PRESSURE 440 PSI 048230
22 VALVE-ACCESS 1/4FL X 3/8 043232
23 VALVE-ACCESS-1/4 MFL X 1/4 047016
24 COMPRESSOR L63A113BBCA 048259-
ITEM DESCRIPTION PART NO.
25 SLEEVE-COMP. MOUNTING 037429
26 GROMMET-COMP. MT 037428
27 SHROUD-CONDENSER SIDE 047167
28 SHROUD-CONDENSER REAR 047166
29 CONDENSER-AC-12LX18H 048233
30 SHROUD-CONDENSER *TOP* 047165
31 SHROUD-CONDENSER 047164
32 BLOWER A. X47833-27
33 CASTER-SWV 5/8 STEM 018794
34 ADAPTOR A.-CASTER X18915
35 CONTROL A. AC SEE PG. 71
36 COVER-CONTROL BOX 033253
37 PANEL A.-FRONT X33237
38 BOLT-CARRIAGE 1/4-20 X 3/4 012347
39 SWITCH-TOGGLE-DPDT 024295
40 BOARD-LOGIC-GEN 2.6-SD X36641SER1
41 SWITCH A.-DRAW X33322-
42 BOX A.-CAP&RELAY SEEPG. 78
43 CAPACITOR-START-60UF 047703
44 COMPRESSOR TL3G-R134A 047701-
44a RELAY-START COMPRESSOR 047702-27
45 VALVE-EPR 1/4S 022665
46 VALVE-ACCESS 1/4FL X 1/4 044404
47 CONDENSER 027155
48 DRYER-CAP. TUBE 047699
49 MOTOR-FAN 105CFM 3000 027309-27
50 SHROUD-DANFOSS 027386
51 GUARD-FAN 028534-1
52* GUIDE A.-DRIP PAN X28863
53 KIT-MOUNTING DANFOSS 047704
*NOT SHOWN
